HB24W600DC-CCT LED Driver (Isolated, Flicker-Free)
Isolated LED driver for ceiling lights, panel lights, downlights, spotlights and fan lights. High power factor 0.95, 85% efficiency, flicker-free output and DIP-switch current adjustment; non-intelligent 0-10V dual-color (CCT) control.
Specifications
- Model
- HB24W600DC CCT
- Output Power
- 15-24 W
- Input
- 100-265 V
- Output
- 22-40 V, 450-600 mA +/-5%
- Efficiency / PF
- 85% / 0.95
- Surge Protection
- 2.5 KV
- Dimensions
- 125*40*22 mm
- Dimming
- 0-10V dual-color CCT, DIP current adjustable
Where It Fits
An isolated LED driver for ceiling lights, panel lights, downlights, spotlights and fan lights. It pairs high power factor with flicker-free output and 0-10V dual-color (CCT) control for non-intelligent fixture lines.
Construction and Specifications
Rated 15-24 W with 100-265 V input and 22-40 V output at 450-600 mA (+/-5%). Efficiency is 85% at power factor 0.95, with 2.5 KV surge protection, in a 125*40*22 mm case. Output is flicker-free with DIP-switch current adjustment and 0-10V dual-color CCT control.
OEM & Ordering Guidance
To specify this driver for your fixture, confirm the output power class, input range, CCT control requirement and mounting dimensions against the specifications listed. DIP-switch current settings and dual-color (CCT) behavior can be matched to your LED configuration. Send your requirement sheet through the contact page for a custom proposal and quotation.
