HB-K01 Integrated Fan Light Control Kit

Complete integrated control kit pairing a wireless receiver unit with an LED-display remote to run ceiling light and ceiling fan as one system. OEM options cover custom silk-screen, surface finish (mirror polish, matte, rubber paint, brushed) and custom startup segment patterns such as your brand logo.

Specifications

Model
HB-K01
System
Receiver + LED-display remote + ceiling light + ceiling fan
Timer
1H-8H
OEM Options
Silk-screen, surface finish, custom segment patterns / brand logo
Compliance
FCC / CE / RoHS

Where It Fits

The HB-K01 pairs a wireless receiver unit with an LED-display remote so a ceiling light and ceiling fan run as one controlled system. It is aimed at fan-light OEM projects that want a single kit covering both fixtures instead of separate light and fan controls.

Construction and Specifications

The kit consists of the HB-K01 receiver unit and a remote with LED segment display including 1H-8H timer. Certification markings include CE and RoHS. OEM options cover silk-screen, surface finish (mirror polish, matte, rubber paint, brushed) and custom startup segment patterns such as a brand logo.

OEM & Ordering Guidance

To configure this remote for your line, confirm the target protocol (IR, RF 433 MHz, 2.4G, Bluetooth, Tuya or Zigbee), key count and layout, display type, housing finish and branding. Silk-screen and surface treatments (mirror polish, matte, rubber paint, brushed) and custom segment patterns such as a startup brand logo are available as OEM options. Send your requirement sheet through the contact page for a custom proposal and quotation.

Start With This Model

011

Ask About This Model

Send the model number with your application and requirements for a project-specific evaluation.

Ask About This Model
022

Discuss Customization

Evaluate key layout, artwork, electronics and housing changes on this platform.

Discuss Customization

CUSTOMIZATION OPTIONS

Customization Options

What can change on this platform - and what needs more than a config change.

A1

Changes Using This Existing Platform

Logo and silk-screen; key artwork and labels; function mapping; housing color and surface finish; PCB and communication-solution review; LCD segment content where a display is fitted. Each item is evaluated against this model's actual structure.

B2

Changes That May Require New Development

Major housing size or structural layout change; additional LCD area; different battery architecture; adding an IR transmission window; major PCB space change; new key arrangement outside the current structure. These go through engineering review before quotation.

PROTOCOL & RECEIVER

Protocol & Receiver Compatibility

A remote is evaluated together with its receiver - not in isolation.

Q11

Can this remote work with my receiver?

Compatibility depends on the receiver, communication method and control logic. Send us your receiver information, existing remote or protocol details for technical evaluation.

Q22

Current configuration vs alternatives

The specifications list the protocol families this model supports per the Hobyte catalog. The shipped configuration is set per project. Alternative communication options require engineering review.

Q33

IR note

If the housing does not provide an IR transmission window, IR compatibility requires housing review before a solution can be confirmed.

OEM DEVELOPMENT

How Can This Model Be Used in an OEM Project?

A1

Use This Model with Minor Changes

Branding, key artwork, function mapping and project-specific electronics review on the existing platform.

B2

Use the Housing with New Electronics

New PCB, MCU, protocol, receiver matching and display logic inside the existing housing structure.

C3

Use It as a Reference for New Development

When the structure does not fully fit, the appearance and layout serve as the reference for a new development.

PROJECT INPUT

What Should You Send Us?

You do not need all of these items. The more you can share, the faster the evaluation.

Q11

Do I need a complete specification?

No. An existing remote, product photo or basic function list can be enough for an initial review.

012

Product & application information

Product application; existing remote or reference sample; drawings / photos if available.

023

Technical & project details

Receiver information; function list; required key functions; protocol / frequency if known; target market; estimated quantity.

TESTING & COMPLIANCE

Testing & Compliance

011

Product certification

Certification and compliance requirements are reviewed according to the communication method, battery design and target market.

022

Project compliance support

Testing requirements and market-entry points are evaluated as part of the project review.
